Industrial Flanges
VEFLOX engineers and supplies a premium range of forged industrial flanges designed to connect piping systems with unyielding strength. Manufactured to exacting dimensional tolerances, our flanges ensure leak-proof performance in high-pressure, extreme-temperature, and critical fluid flow applications.
Precision CNC Machined
Technical Specifications
Materials & Grades
Carbon Steel: ASTM A105/A105N, A350 LF2, A694 F42-F70
Stainless Steel: ASTM A182 F304/304L, F316/316L, F321, F347
Alloys & Duplex: ASTM A182 F51, F53, Inconel, Monel, Hastelloy
Stainless Steel: ASTM A182 F304/304L, F316/316L, F321, F347
Alloys & Duplex: ASTM A182 F51, F53, Inconel, Monel, Hastelloy
Dimensional Standards
ASME/ANSI B16.5, ASME B16.47 (Series A & B), EN 1092-1, DIN, BS 4504, AWWA C207, JIS B2220
Pressure Ratings (Class)
ASME/ANSI: Class 150#, 300#, 600#, 900#, 1500#, 2500#
DIN/EN: PN6, PN10, PN16, PN25, PN40, PN64, PN100
DIN/EN: PN6, PN10, PN16, PN25, PN40, PN64, PN100
Flange Facing Types
Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ), Tongue & Groove (T&G), Male & Female (M&F)
Size Range
1/2" NB to 60" NB (Custom large diameter flanges engineered upon request)
Manufacturing Process
Drop Forged & CNC Precision Machined, Heat Treated, 100% Traceable
Core Advantages
Dimensional Accuracy
Precision-machined tolerances ensure perfect alignment and flawless welding during installation.
High Tensile Strength
Forged construction prevents structural deformation under extreme hydrostatic pressure.
Corrosion Resistance
Premium alloy grades provide superior longevity in highly acidic and chemical environments.
Industries Served
Oil & Gas
Petrochemicals
Power Generation
Water Treatment
Shipbuilding
Pharmaceuticals
